USB / USB EDC
8GB ~ 128GB
USB EDC Horizontal 2IE4
Features
- High performance with USB 2.0 interface
- Wear-Leveling supported
- Low power consumption
- ECC capability up to 72-bit / 1024 Bytes
- Pin pitch 2.54mm
- Supports wide temperature from -40°C to 85°C
The Innodisk USB EDC (Embedded Disk Card) provides high capacity USB Flash storage that electrically complies with USB 2.0. The device features a compact form factor, connectivity over USB 2.0 and the NAND Flash architecture, providing fast data transmission.
Wear Leveling Technology – EXTENDING PRODUCT LIFESPAN
Innodisk adopts innovative wear leveling technology to revolutionize Flash storage methods, thereby improving its lifespan. By applying this technology to both dynamic and static storage blocks, it eliminates the traditional concepts of hot zones and cold zones, achieving full-area wear balance and optimizing the use of every flash memory block.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
COMMUNICATION
Our solutions ensure reliable and uninterrupted performance, supporting networking and critical telecom infrastructure even under heavy loads.
TRANSPORTATION
Our solutions enhance operations, management, and security for EVs, buses, subways, and more.
RETAIL
Powering smart retail systems, our solutions enable efficient inventory management, seamless point-of-sale operations, and insightful customer analytics.
仕様
| Model Name | USB EDC Horizontal 2IE4 |
|---|---|
| Flash Type | iSLC (3D TLC) |
| Interface | USB 2.0 |
| Form Factor | USB EDC Horizontal |
| Capacity | 8GB ~ 128GB |
| Sequential R / W (MB/sec, max.) | 40 / 25 |
| P/E Cycle | 20,000 |
| TBW (Max.) | 2,000 |
| Storage Temperature | -40°C ~ 85°C |
| Max. Power Consumption | 0.5W |
| Max. Channels | 2 |
| External DRAM Buffer | N |
| Features | S.M.A.R.T. |
| Dimension (W x L x H/mm) | Pin Pitch 2.54: 26.6 x 36.9 x 9.85 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 5 Years |
注文情報
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
8GB | DHUH1-08GID1KCCSF | DHUH1-08GID1KWCSF |
16GB | DHUH1-16GID1KCCSF | DHUH1-16GID1KWCSF |
32GB | DHUH1-32GID1KCCDF | DHUH1-32GID1KWCDF |
64GB | DHUH1-64GID1KCCDF | DHUH1-64GID1KWCDF |
128GB | DHUH1-A28ID1KCCDF | DHUH1-A28ID1KWCDF |
