DDR4
Registered Memory with ECC
DDR4 Wide Temp. RDIMM VLP
Features
- Register that enhances clock, command, and control signals
- ECC DIMM incorporates error correction and detection capabilities
- Fully tested and optimized for stability and performance
- Uses original IC to meet strict industrial standards
- Anti-sulfuration protection against harsh environments
- JEDEC standard 1.2V (1.26V ~ 1.14V)
- Operating Environment: -40°C ~ 95°C (Tc)
- RoHS Compliance, CE / FCC Certification
DDR4 Wide Temperature RDIMM VLP is a very low-profile design that offers the industry's fastest memory speed with 3200MT/s, and it is fully compatible with the Intel® Purely platform and 1U devices. The modules come equipped with 30μ” Gold Finger and include single bit error correction and a register to enhance clock, command, and control signals. The modules comply with all relevant JEDEC standards and can operate in temperatures from -40ºC to 95°C (Tc).
VLP DIMM modules are specialized for use in 1U systems, such as blade server data centers, where system height is lower than 1.18 inches. The design of these modules improves airflow inside the system and reduces thermal impact.
ECC function is designed to detect and correct single-bit errors that occur during data storage and transmission. ECC modules use Hamming Code or Triple Modular Redundancy for error detection and correction, and manage error corrections on their own, without requesting that the data source resend the original data.
SAFEGUARDING MODULES WITH ANTI-SULFURATION PROTECTIVE LAYER
Sulfur is pervasive in many industries. When silver alloys in the DRAM chip encounters sulfur gasses a corrosion reaction occurs. This sulfuration causes lower conductivity and can quickly lead to product failure. To avoid this, Innodisk adds a protective layer above the vulnerable parts to safeguard the silver alloys.
TAILORED TO YOUR SPECIFIC NEEDS
SIDE FILL
Side Fill reinforces the connection between chips and the board, providing superior protection in environments with high vibration or mechanical stress.
CONFORMAL COATING
Conformal Coating applies a protective acrylic layer over the DRAM PCB, shielding it from harmful elements such as moisture, dust, and corrosive substances.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
EDGE SERVER
Designed for edge computing, our products ensure stable performance in harsh conditions, supporting real-time data processing at the edge device.
DATA CENTER
Driving the backbone of modern computing, our solutions deliver high performance and reliability for data-intensive operations.
SURVEILLANCE & SAFETY
Our solutions deliver advanced analytics and instant response for modern surveillance needs.
COMMUNICATION
Our solutions ensure reliable and uninterrupted performance, supporting networking and critical telecom infrastructure even under heavy loads.
規格表
| Model Name | DDR4 Wide Temperature RDIMM VLP |
|---|---|
| DDR Generation | DDR4 Memory |
| DIMM Type | RDIMM VLP |
| Speed | 2133 MT/s, 2400 MT/s, 2666 MT/s, 2933 MT/s, 3200 MT/s |
| Density | 4GB, 8GB, 16GB, 32GB |
| Function | Registered Memory with ECC |
| Pin Number | 288pin |
| Bus Width | x72 |
| Voltage | 1.2V |
| PCB Height | 0.738 Inches |
| Operating Temperature | -40°C ~ 95°C (Tc) |
| 30μ” Gold Finger | Y |
| Anti-Sulfuration | Y |
| Notice | 4GB is only for 2133MT/s and 2400MT/s |
產品料號
P/N | IC Config. | Rank | Temp. | Description |
M4R0-4GSSC5EM | 512M x 8 | 1R x 8 | -40°C ~ 95°C (Tc) | DDR4 3200 4GB Wide Temperature RDIMM VLP |
M4R0-8GSSD5EM | 512M x 8 | 2R x 8 | -40°C ~ 95°C (Tc) | DDR4 3200 8GB Wide Temperature RDIMM VLP |
M4R0-8GS1C5EM | 1G x 8 | 1R x 8 | -40°C ~ 95°C (Tc) | DDR4 3200 8GB Wide Temperature RDIMM VLP |
M4R0-AGS1D5EM | 1G x 8 | 2R x 8 | -40°C ~ 95°C (Tc) | DDR4 3200 16GB Wide Temperature RDIMM VLP |
M4R0-AGS2C5EM | 2G x 8 | 1R x 8 | -40°C ~ 95°C (Tc) | DDR4 3200 16GB Wide Temperature RDIMM VLP |
M4R0-BGS2D5EM | 2G x 8 | 2R x 8 | -40°C ~ 95°C (Tc) | DDR4 3200 32GB Wide Temperature RDIMM VLP |
*Please contact Innodisk for products with other speeds.
