DDR3
Non-ECC Unbuffered Memory
DDR3 Wide Temp. UDIMM
Features
- Fully tested and optimized for stability and performance
- Uses original IC to meet strict industrial standards
- JEDEC standard 1.5V (1.425V ~ 1.575V) & 1.35V (1.28V ~ 1.45V)
- Operating Environment: -40°C ~ 85°C
- 30μ” Gold Finger
- RoHS Compliance
- CE / FCC Certification
The DDR3 Wide Temperature UDIMM is an industrial memory module that provides lasting performance and is designed for the in-vehicle automation and embedded markets. The modules comply with all relevant JEDEC standards, can operate in temperatures from -40ºC to 85ºC, and are available in 2GB, 4GB, and 8GB capacities. Data transfer rates of 1066MT/s, 1333MT/s, 1600MT/s, and 1866MT/s are available.
TAILORED TO YOUR SPECIFIC NEEDS
SIDE FILL
Side Fill reinforces the connection between chips and the board, providing superior protection in environments with high vibration or mechanical stress.
CONFORMAL COATING
Conformal Coating applies a protective acrylic layer over the DRAM PCB, shielding it from harmful elements such as moisture, dust, and corrosive substances.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
TRANSPORTATION
Our solutions enhance operations, management, and security for EVs, buses, subways, and more.
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
規格表
| Model Name | DDR3 Wide Temperature UDIMM |
|---|---|
| DDR Generation | DDR3 Memory |
| DIMM Type | UDIMM |
| Speed | 1066 MT/s, 1333 MT/s, 1600 MT/s, 1866 MT/s |
| Density | 2GB, 4GB, 8GB |
| Function | Non-ECC Unbuffered Memory |
| Pin Number | 240pin |
| Bus Width | x64 |
| Voltage | 1.35V, 1.5V |
| PCB Height | 1.18 Inches |
| Operating Temperature | -40°C ~ 85°C |
| 30μ” Gold Finger | Y |
產品料號
P/N | IC Config. | Rank | Temp. | Description |
M3U0-2GMJB5QE | 256M x8 | 1R x 8 | -40°C ~ 85°C | DDR3 1866 2GB Wide Temperature UDIMM |
M3U0-4GMJA5QE | 256M x8 | 2R x 8 | -40°C ~ 85°C | DDR3 1866 4GB Wide Temperature UDIMM |
M3U0-4GMSB5QE | 512M x8 | 1R x 8 | -40°C ~ 85°C | DDR3 1866 4GB Wide Temperature UDIMM |
M3U0-8GMSA5QE | 512M x8 | 2R x 8 | -40°C ~ 85°C | DDR3 1866 8GB Wide Temperature UDIMM |
M3U0-2GMJB4QE | 256M x8 | 1R x 8 | -40°C ~ 85°C | DDR3L 1866 2GB Wide Temperature UDIMM |
M3U0-4GMSB4QE | 512M x8 | 1R x 8 | -40°C ~ 85°C | DDR3L 1600 4GB Wide Temperature UDIMM |
M3U0-4GMJA4QE | 256M x8 | 2R x 8 | -40°C ~ 85°C | DDR3L 1866 4GB Wide Temperature UDIMM |
M3U0-8GMSA4QE | 512M x 8 | 2R x 8 | -40°C ~ 85°C | DDR3L 1866 8GB Wide Temperature UDIMM |
*Please contact Innodisk for products with other speeds.
