CFast
8GB ~ 256GB
CFast 3ME4
Features
- Innovative firmware algorithm
- DRAM-less, 100% data integrity
- Excellent random performance
- Supports TRIM / NCQ / SMART
- Supports wide temperature from -40°C to 85°C
Innodisk CFast 3ME4 is characterized by L³ architecture with the latest SATA III (6.0GHz) controller. Innodisk’s exclusive L³ architecture is L² architecture multiplied LDPC (Low Density Parity Check). L² (Long Life) architecture is a 4K mapping algorithm that reduces WAF and features a real-time wear leveling algorithm to provide high performance and prolong lifespan with exceptional reliability.
Without additional driver, CFast 3ME4, featured as small form factor, can be configured as a boot device or data storage and is suitable for most industrial application. Supported with hardware write protection, CFast 3ME4 can prevent valuable data on a device from modification and deletion.
Innodisk CFast 3ME4 is designed for industrial field, and supports several standard features, including TRIM, NCQ, and S.M.A.R.T. In addition, Innodisk’s exclusive industrial-oriented firmware provides a flexible customization service, making it perfect for a variety of industrial applications.
Garbage Collection and TRIM Technologies – OPTIMIZING SSD PERFORMANCE
Garbage Collection is a process where data that is still in use is copied to a new block, and the old block is then cleared of all data. With TRIM technology, the number of operations required for Garbage Collection is minimized, reducing unnecessary wear on the SSD and enhancing its longevity.
Wear Leveling Technology – EXTENDING PRODUCT LIFESPAN
Innodisk adopts innovative wear leveling technology to revolutionize SSD storage methods, thereby improving its lifespan. By applying this technology to both dynamic and static storage blocks, it eliminates the traditional concepts of hot zones and cold zones, achieving full-area wear balance and optimizing the use of every flash memory block.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
規格表
| Model Name | CFast 3ME4 |
|---|---|
| Flash Type | MLC |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | CFast 2.0 |
| Capacity | 8GB ~ 256GB |
| Sequential R / W (MB/sec, max.) | 530 / 210 |
| P/E Cycle | 3,000 |
| TBW (Max.) | 416 |
| Storage Temperature | -55°C ~ 95°C |
| Max. Power Consumption | 1W |
| Max. Channels | 2 |
| External DRAM Buffer | N |
| Feature | H/W Write Protect, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 42.8 x 36.4 x 3.6 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 2 Years |
產品料號
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
8GB | DECFA-08GM41BC1SC(W) | DECFA-08GM41BW1SC(W) |
16GB | DECFA-16GM41BC1&C(W) | DECFA-16GM41BW1&C(W) |
32GB | DECFA-32GM41BC1DC(W) | DECFA-32GM41BW1DC(W) |
64GB | DECFA-64GM41BC1DC(W) | DECFA-64GM41BW1DC(W) |
128GB | DECFA-A28M41BC1DC(W) | DECFA-A28M41BW1DC(W) |
256GB | DECFA-B56M41BC1DC(W) | DECFA-B56M41BW1DC(W) |
&. S : 1 channel / D : 2 channels
