CFast
16GB ~ 128GB
CFast 3IE2-P
Features
- High sequential / IOPS performance
- Intelligent error recovery system
- iSMART for disk health monitoring
- iData Guard for abnormal power failure
- Supports TRIM / NCQ / SMART
- Supports iSLC technology
- Supports wide temperature from -40°C to 85°C
Innodisk CFast 3IE2-P is iSLC series which is designed to outdo the endurance, performance and reliability of MLC-based solutions. Through the use of Flash management algorithms, iSLC improves SSD endurance up to 20,000 times, increasing lifespans up to 7 times longer than MLC-based solutions. In addition, iSLC improves the performance of solid state drives, with similar write performance of SLC-based solutions. Innodisk iSLC series is cost efficient, boasting excellent benefits at only half the price of SLC-based solutions.
Innodisk CFast 3IE2-P is characterized by L³ architecture with the latest SATA III (6.0GHz) controller. Innodisk’s exclusive L³ architecture is L² architecture multiplied LDPC (Low Density Parity Check). L² (Long Life) architecture is a 4K mapping algorithm that reduces WAF and features a real-time wear leveling algorithm to provide high performance and prolong lifespan with exceptional reliability.
Innodisk CFast 3IE2-P is designed for industrial field, and supports several standard features, including TRIM, NCQ, and S.M.A.R.T. In addition, Innodisk’s exclusive industrial-oriented firmware provides a flexible customization service, making it perfect for a variety of industrial applications.
iData Guard – DATA PROTECTION TECHNOLOGY
iData Guard enables the immediate sending of a command in the event of a sudden power failure, interrupting read and write commands from the system and ensuring that the last command can be completed. This preserves data integrity on the SSD, protecting data security.
Wear Leveling Technology – EXTENDING PRODUCT LIFESPAN
Innodisk adopts innovative wear leveling technology to revolutionize SSD storage methods, thereby improving its lifespan. By applying this technology to both dynamic and static storage blocks, it eliminates the traditional concepts of hot zones and cold zones, achieving full-area wear balance and optimizing the use of every flash memory block.
AES 256-bit DATA ENCRYPTION & TCG Opal 2.0 SUPPORT
Innodisk SSDs utilize AES 256-bit encryption, the US government’s standard for securing confidential data, while also supporting TCG Opal 2.0 for enhanced device management and user-friendly authentication.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
規格表
| Model Name | CFast 3IE2-P |
|---|---|
| Flash Type | iSLC (MLC) |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | CFast 2.0 |
| Capacity | 16GB ~ 128GB |
| Sequential R / W (MB/sec, max.) | 550 / 460 |
| P/E Cycle | 20,000 |
| TBW (Max.) | 1,250 |
| Storage Temperature | -40°C ~ 85°C |
| Max. Power Consumption | 2.1W |
| Max. Channels | 4 |
| External DRAM Buffer | Y |
| Feature | AES, TCG Opal 2.0, H/W Write Protect, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 42.8 x 36.4 x 3.6 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 5 Years |
產品料號
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
16GB | DHCFA-16GD81BCADC(W) | DHCFA-16GD81BWADC(W) |
32GB | DHCFA-32GD81BCAQC(W) | DHCFA-32GD81BWAQC(W) |
64GB | DHCFA-64GD81BCAQC(W) | DHCFA-64GD81BWAQC(W) |
128GB | DHCFA-A28D81BCAQC(W) | DHCFA-A28D81BWAQC(W) |
(W) : H/W write protect function (Optional)
