M.2
PCIe Gen4 Solution
M.2 (P30) 4TE3
Features
- Powered by PCIe Gen 4 x4 and NVMe 1.4, delivering fast and reliable performance
- Supports temperatures -40°C to 85°C with dynamic thermal throttling to maintain SSD stability
Innodisk M.2 (P30) 4TE3 is a PCIe Gen 4 x4 interface and 3D TLC NAND Flash while adhering to the NVMe 1.4 protocol, delivering exceptional performance and high reliability. Equipped with Error Correction Code (ECC) technology, the M.2 (P30) 4TE3 provides comprehensive End-to-End Data Path Protection (ETEP), ensuring secure data transmission between the host system and NAND Flash.
AES 256-bit DATA ENCRYPTION & TCG Opal 2.0 SUPPORT
Innodisk SSDs utilize AES 256-bit encryption, the US government’s standard for securing confidential data, while also supporting TCG Opal 2.0 for enhanced device management and user-friendly authentication.
TAILORED TO YOUR SPECIFIC NEEDS
HEAT SINK CUSTOMIZATION
Innodisk provides different types of heat sinks to meet your specific storage needs.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
COMMUNICATION
Our solutions ensure reliable and uninterrupted performance, supporting networking and critical telecom infrastructure even under heavy loads.
RETAIL
Powering smart retail systems, our solutions enable efficient inventory management, seamless point-of-sale operations, and insightful customer analytics.
SPECIFICATIONS
| Model Name | M.2 (P30) 4TE3 |
|---|---|
| Flash Type | 3D TLC |
| Interface | PCIe Gen 4 x4 |
| Form Factor | M.2 2230 M Key |
| Capacity | 128GB ~ 1TB |
| Sequential R / W (MB/sec, max.) | 1,800 / 1,500 |
| P/E Cycle | 3,000 |
| TBW (Max.) | 932 |
| Storage Temperature | -40°C ~ 85°C |
| Max. Power Consumption | 3.1W |
| Max. Channels | 4 |
| External DRAM Buffer | N |
| Features | AES, TCG Opal 2.0, S.M.A.R.T. |
| Dimension (W x L x H/mm) | Pure M.2 : 22.0 x 30.0 x 3.5 W/T with heat sink : 25.0 x 30.0 x 15.0 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 3 Years |
ORDER INFORMATION
Operating Temperature | Standrad Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
128GB | DEM23-A28DH1KCBDF | DEM23-A28DH1KWBDFH |
256GB | DEM23-B56DH1KCBDF | DEM23-B56DH1KWBDFH |
512GB | DEM23-C12DH1KCBDF | DEM23-C12DH1KWBDFH |
1TB | DEM23-01TDH1KCBDF | DEM23-01TDH1KWBDFH |
For TCG Opal function, the PN Code 10th ~ 12th will be DH2.
