mSATA
8GB ~ 64GB
mSATA mini 3IE3
Features
- SATA 6.0Gb/s interface
- iSMART disk health monitoring
- Intelligent error recovery system
- Excellent data transfer speed
- Zero mechanical interference
- Anti-vibration mechanical design
- JEDEC standard MO-300 dimension
- Supports wide temperature from -40°C to 85°C
Innodisk mSATA mini 3IE3 is designed with mSATA mini form factor by MO-300/MO-300B which established by JEDEC, and support SATA III standard (6.0Gb/s) with excellent performance. Regarding of mechanical interference, Innodisk mSATA mini 3IE3 absolutely replaces the traditional hard disk and makes personal computer, in any field, smaller and easier.
Innodisk mSATA mini 3IE3 effectively reduces the booting time of operation system, and the power consumption is less than hard disk drive (HDD), and complies with ATA protocol, no additional drives are required, and can be configured as a boot device or data storage device.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
SPECIFICATIONS
| Model Name | mSATA mini 3IE3 |
|---|---|
| Flash Type | iSLC (MLC) |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | MO-300B |
| Capacity | 8GB ~ 64GB |
| Sequential R / W (MB/sec, max.) | 230 / 170 |
| P/E Cycle | 20,000 |
| TBW (Max.) | 173 |
| Storage Temperature | -55°C ~ 95°C |
| Max. Power Consumption | 0.6W |
| Max. Channels | 2 |
| External DRAM Buffer | N |
| Feature | S.M.A.R.T. |
| Dimension (W x L x H/mm) | 29.85 x 26.8 x 3.7 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 5 Years |
ORDER INFORMATION
| Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
8GB | DHMSM-08GD09BC1SC | DHMSM-08GD09BW1SC |
16GB | DHMSM-16GD09BC1DC | DHMSM-16GD09BW1DC |
32GB | DHMSM-32GD09BC1DC | DHMSM-32GD09BW1DC |
64GB | DHMSM-64GD09BC1DC | DHMSM-64GD09BW1DC |
