EV2U-SSM1

Product Features

USB 2.0 Interface, 1920 x 1080 @30fps (Max Resolution)
Support Low Light Condition, ISP Inside
Lens FOV ( D / H / V ) : 121°/ 102 °/ 54°
OS Support : Windows, Linux, Android, macOS (UVC)
Compliant to USB 2.0 and USB Video Class
Complies with CE / FCC Class A

Featured Technologies:

Application:

Specs Order Information Related Resource +ADD TO INQUIRY

Specifications:

Module Name	EV2U-SSM1
Module Type	USB 2.0 2MP Fixed Focus Camera Module
Resolution	1920x1080 @ 30fps
Output I/F	USB 2.0
Power consumption	Approximate 1W ( MJPEG @Full Resolution)
Operating Temperature	Operation: -20°C ~ +70°C
Sensor Size	1/2.8”
Pixel Size	2.9µm
Lens type	Fixed Focus (M12)
Dimensions (W x L x H/mm)	38 x 38 x 26.6
Lens D/H/V FOV	121° / 102° / 54°
OS Support	Windows, Linux, Android, MacOS
Shutter	Rolling
Video Format	YUV422, MJPEG

Order Information:

P/N	Description
EV2U-SSM1-RLCF-11	USB 2.0 2MP Fixed Focus Camera Module (USB cable included) Dimension : 38 x 38mm
EV2U-SSM1-RLCF-12	USB 2.0 2MP Fixed Focus Camera Module, with DMIC (USB cable included) Dimension : 38 x 38mm
EV2U-SSM1-RLCF-A1	USB 2.0 2MP Fixed Focus Camera Module (USB cable included) Dimension : 32 x 32mm
EV2U-SSM1-RLCF-A2	USB 2.0 2MP Fixed Focus Camera Module, with DMIC (USB cable included) Dimension : 32 x 32mm
EV2U-SSM1-RLCF-21	USB 2.0 2MP Fixed Focus Camera Module, with Housing (USB cable included) Dimension : 41.4 x 41.4mm
7W2000000160	USB 2.0 cable 1 meter, 5 pins, pitch 1mm
