DDR3
Non-ECC Unbuffered Memory
DDR3 SODIMM
Features
- Small outline dual in-line memory module
- Fully tested and optimized for stability and performance
- Uses original IC to meet strict industrial standards
- JEDEC Standard 1.5V (1.425V~1.575V) & 1.35V (1.28V~1.45V)
- Operating Environment: 0°C ~ 85°C
- RoHS Compliance
- CE / FCC Certification
DDR3 SODIMM memory (small outline) is a compact industrial standards memory module that fits neatly into any embedded, surveillance and automation setup. DDR3 SODIMM memory comply with all relevant JEDEC standards and are available in 1GB, 2GB, 4GB, and 8GB capacities and with data transfer rates of 1066MT/s, 1333MT/s, 1600MT/s, and 1866MT/s.
PROVEN RELIABILITY THROUGH 3rd PARTY TESTING
Ensuring the durability and reliability of components is essential for meeting the demands of challenging environments. Our solutions undergo rigorous third-party testing, adhering to stringent industry standards. These tests validate the robustness of our products under extreme conditions, ensuring dependable performance across various applications.
| Package Drop Test | Drop Height 76 cm, ISTA-1A |
| Thermal Shock | -40°C ~ 110°C, 500 Cycles |
| DRAM Module Insert & Extract Test | 100 Cycles, EIA-364-9 |
TAILORED TO YOUR SPECIFIC NEEDS
SIDE FILL
Side Fill reinforces the connection between chips and the board, providing superior protection in environments with high vibration or mechanical stress.
CONFORMAL COATING
Conformal Coating applies a protective acrylic layer over the DRAM PCB, shielding it from harmful elements such as moisture, dust, and corrosive substances.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
Ensuring Safety Through Customized Solution for MRI Machines and NMR Equipment
Anti-magnetic components are required if systems or devices are placed directly in the magnetic field present near MRI and NMR equipment.
SPECIFICATIONS
| Model Name | DDR3 SODIMM |
|---|---|
| DDR Generation | DDR3 Memory |
| DIMM Type | SODIMM |
| Speed | 1066 MT/s, 1333 MT/s, 1600 MT/s, 1866 MT/s |
| Density | 1GB, 2GB, 4GB, 8GB |
| Function | Non-ECC Unbuffered Memory |
| Pin Number | 204pin |
| Bus Width | x64 |
| Voltage | 1.35V, 1.5V |
| PCB Height | 1.18 Inches |
| Operating Temperature | 0°C ~ 85°C |
ORDER INFORMATION
P/N | IC Config. | Rank | Temp. | Description |
M3S0-1GMWFCQE | 128M x 16 | 1R x 16 | 0°C ~ 85°C | DDR3 1866 1GB SODIMM |
M3S0-2GMJCCQE | 256M x 8 | 1R x 8 | 0°C ~ 85°C | DDR3 1866 2GB SODIMM |
M3S0-2GMVFCQE | 256M x 16 | 1R x 8 | 0°C ~ 85°C | DDR3 1866 2GB SODIMM |
M3S0-4GMV0CQE | 256M x 16 | 2R x 16 | 0°C ~ 85°C | DDR3 1866 4GB SODIMM |
M3S0-4GMJDCQE | 256M x 8 | 2R x 8 | 0°C ~ 85°C | DDR3 1866 4GB SODIMM |
M3S0-4GMSCCQE | 512M x 8 | 1R x 16 | 0°C ~ 85°C | DDR3 1866 4GB SODIMM |
M3S0-8GMSDCQE | 512M x 8 | 2R x 16 | 0°C ~ 85°C | DDR3 1866 8GB SODIMM |
M3S0-1GMWFLQE | 128M x 16 | 1R x 16 | 0°C ~ 85°C | DDR3L 1866 1GB SODIMM |
M3S0-2GMJCLQE | 256M x 8 | 1R x 8 | 0°C ~ 85°C | DDR3L 1866 2GB SODIMM |
M3S0-2GMVFLQE | 256M x 16 | 1R x 8 | 0°C ~ 85°C | DDR3L 1866 2GB SODIMM |
M3S0-4GMJDLQE | 256M x 8 | 2R x 8 | 0°C ~ 85°C | DDR3L 1866 4GB SODIMM |
M3S0-4GMV0LQE | 256M x 16 | 2R x 8 | 0°C ~ 85°C | DDR3L 1866 4GB SODIMM |
M3S0-4GMSCLQE | 512M x 8 | 1Rx 8 | 0°C ~ 85°C | DDR3L 1866 4GB SODIMM |
M3S0-8GMSDLQE | 512M x 8 | 2R x 8 | 0°C ~ 85°C | DDR3L 1866 8GB SODIMM |
*Please contact Innodisk for products with other speeds.
