2.5” SATA SSD 3TS6-P

Product Features
  • 2.5” SATA III solution for Edge Server field
  • High IOPS
  • iSMART disk health monitoring
  • AES-256 encryption
  • End to end data path protection
  • iData Guard for abnormal power failure
  • iCell technology for data protection
  • iPower Guard for protecting unstable start up and shut down
Featured Technologies:
Application:
Overview Specs Order Information Related Resource +ADD TO INQUIRY

Overview:

Innodisk 2.5” SATA SSD 3TS6-P is SATA III 6Gb/s solid state disk, which delivers excellent performance, especially in random data transfer rate, and offers great reliability making it the ideal solution for a variety of applications, including embedded system, industrial computing, and enterprise field. 3TS6-P 2.5” SSD not only performs unmatched performance, but also designed with Innodisk owned technical knowhow to ensure the data integrity and highest levels of reliability.

Specifications:

Model Name2.5” SATA SSD 3TS6-P
InterfaceSATA III 6.0 Gb/s
Flash Type3D TLC
Capacity200GB~3.2TB
Sequential R/W (MB/sec, max.)510/460
Max. Power Consumption5.0 W
Max. Channels4
Thermal SensorY
External DRAM BufferY
AES EncryptionOptional
S.M.A.R.T.Y
ATA SecurityY
Dimension (WxLxH/mm)69.8 x 100.0 x 7.0 (128GB ~ 4TB, Single Board)
69.8 x 100.0 x 9.5 (4TB/8TB, Dual Board)
Vibration[email protected]~2000Hz
Shock[email protected]
MTBF>3 million hours
Storage Temperature-40°C ~ +85°C

Order Information:

Operation Temp. 200GB 400GB 800GB 1.6TB 3.2TB
Standard Grade (0°C ~ +70°C) DSS25-200M71KCADFP DSS25-400M71KCAQFP DSS25-800M71KCAQFP DSS25-1T6M71KCAQFP DSS25-3T2M71KCAQFP
