2.5" SSD
8GB ~ 256GB
2.5” SATA SSD 3ME4
Features
- 2.5” SATA III solution for industrial field
- DRAM-less, high-level data integrity
- Excellent IOPS boosts system performance
- Built-in thermal sensor
- Supports S.M.A.R.T., TRIM and NCQ
- Supports wide temperature from -40°C to 85°C
Innodisk 2.5” SATA SSD 3ME4 is characterized by L³ architecture with the latest SATA III (6.0GHz) controller. Innodisk’s exclusive L³ architecture is L² architecture multiplied LDPC (Low Density Parity Check). L² (Long Life) architecture is a 4K mapping algorithm that reduces WAF and features a real-time wear leveling algorithm to provide high performance and prolong lifespan with exceptional reliability.
Garbage Collection and TRIM Technologies – OPTIMIZING SSD PERFORMANCE
Garbage Collection is a process where data that is still in use is copied to a new block, and the old block is then cleared of all data. With TRIM technology, the number of operations required for Garbage Collection is minimized, reducing unnecessary wear on the SSD and enhancing its longevity.
Wear Leveling Technology – EXTENDING PRODUCT LIFESPAN
Innodisk adopts innovative wear leveling technology to revolutionize SSD storage methods, thereby improving its lifespan. By applying this technology to both dynamic and static storage blocks, it eliminates the traditional concepts of hot zones and cold zones, achieving full-area wear balance and optimizing the use of every flash memory block.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
SPECIFICATIONS
| Model Name | 2.5” SATA SSD 3ME4 |
|---|---|
| Flash Type | MLC |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | 2.5" SSD |
| Capacity | 8GB ~ 256GB |
| Sequential R / W (MB/sec, max.) | 530 / 210 |
| P/E Cycle | 3,000 |
| TBW (Max.) | 416 |
| Storage Temperature | -55°C ~ 95°C |
| Max. Power Consumption | 0.8W |
| Max. Channels | 2 |
| External DRAM Buffer | N |
| Feature | S.M.A.R.T. |
| Dimension (W x L x H/mm) | 69.85 x 100.0 x 6.9 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 2 Years |
ORDER INFORMATION
| Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
8GB | DES25- 08GM41BC1SC | DES25- 08GM41BW1SC |
16GB | DES25-16GM41BC1&C | DES25-16GM41BW1&C |
32GB | DES25-32GM41BC1DC | DES25-32GM41BW1DC |
64GB | DES25-64GM41BC1DC | DES25-64GM41BW1DC |
128GB | DES25-A28M41BC1DC | DES25-A28M41BW1DC |
256GB | DES25-B56M41BC1DC | DES25-B56M41BW1DC |
&. S : 1 channel / D : 2 channels
