2.5" SSD
8GB ~ 512GB
2.5" SATA SSD 3IE2-P
Features
- 2.5" SATA III solution for industrial field
- 7mm height mechanical design
- iSMART disk health monitoring
- High IOPS to enhance boot up timing
- iData Guard Protection
Innodisk 2.5" SATA SSD 3IE2-P is SATA III 6.0Gb/s Flash based disk with iSLC technology, which delivers excellent performance and reliability making it the ideal solution for a variety of applications, including embedded system, industrial computing, and enterprise field.
2.5" SATA SSD 3IE2-P not only performs unmatched performance, but also designed with Innodisk owned technical knowhow to ensure the data integrity and highest levels of reliability.
iCell Technology – POWER LOSS PROTECTION
Innodisk's iCell Technology safeguards mission-critical data on DRAM-based SSDs during unexpected power failures. Integrated iCells deliver an instantaneous charge to ensure data is securely stored, preventing any loss and ensuring data integrity.
AES 256-bit DATA ENCRYPTION & TCG Opal 2.0 SUPPORT
Innodisk SSDs utilize AES 256-bit encryption, the US government’s standard for securing confidential data, while also supporting TCG Opal 2.0 for enhanced device management and user-friendly authentication.
iData Guard – DATA PROTECTION TECHNOLOGY
iData Guard enables the immediate sending of a command in the event of a sudden power failure, interrupting read and write commands from the system and ensuring that the last command can be completed. This preserves data integrity on the SSD, protecting data security.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
SPECIFICATIONS
| Model Name | 2.5" SATA SSD 3IE2-P |
|---|---|
| Flash Type | iSLC (MLC) |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | 2.5" SSD |
| Capacity | 8GB ~ 512GB |
| Sequential R / W (MB/sec, max.) | 530 / 450 |
| P/E Cycle | 20,000 |
| TBW (Max.) | 10,000 |
| Storage Temperature | -55°C ~ 95°C |
| Max. Power Consumption | 2.3W |
| Max. Channels | 4 |
| External DRAM Buffer | Y |
| Feature | PLP (iCell), AES, TCG Opal 2.0, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 69.85 x 100.0 x 6.9 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 5 Years |
ORDER INFORMATION
| Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
| 8GB | DHS25-08GD81BC*DC(P) | DHS25-08GD81BW*DC(P) |
16GB | DHS25-16GD81BC*&C(P) | DHS25-16GD81BW*&C(P) |
32GB | DHS25-32GD81BC*QC(P) | DHS25-32GD81BW*QC(P) |
64GB | DHS25-64GD81BC*QC(P) | DHS25-64GD81BW*QC(P) |
128GB | DHS25-A28D81BC*QC(P) | DHS25-A28D81BW*QC(P) |
256GB | DHS25-B56D81BC1QC(P) | DHS25-B56D81BW1QC(P) |
512GB | DHS25-C12D81BCAQC(P) | DHS25-C12D81BWAQC(P) |
*. PCB version control
&. S : 1channel /D : 2 channels /Q : 4 channels
(P) : PLP (iCell) (Optional)
For TCG OPAL function, the PN Code 10th ~ 12th will be D82.
