DDR4 Wide Temp. SODIMM

DDR4

Non-ECC Unbuffered Memory

DDR4 Wide Temp. SODIMM

Features

  • Small outline dual in-line memory module
  • Fully tested and optimized for stability and performance
  • Uses original IC to meet strict industrial standards
  • Anti-sulfuration protection against harsh environments
  • JEDEC standard 1.2V (1.26V ~ 1.14V)
  • Operating Environment: -40°C ~ 95°C (Tc)
  • 30μ” Gold Finger
  • RoHS Compliance, CE / FCC Certification

BORN FOR SUPERIOR PERFORMANCE

DDR4 Wide Temperature SODIMM offers a compact design and the industry's fastest memory speed with 3200MT/s - the perfect fit for any in-vehicle, surveillance, automation and embedded application. The modules comply with all relevant JEDEC standards, can operate in temperatures from -40ºC to 95°C (Tc), and are available in 4GB, 8GB, 16GB, and 32GB capacities. 2133MT/s, 2400MT/s and 2666MT/s modules are also available.

SAFEGUARDING MODULES WITH ANTI-SULFURATION PROTECTIVE LAYER

Sulfur is pervasive in many industries. When silver alloys in the DRAM chip encounters sulfur gasses a corrosion reaction occurs. This sulfuration causes lower conductivity and can quickly lead to product failure. To avoid this, Innodisk adds a protective layer above the vulnerable parts to safeguard the silver alloys.


   Anti-Sulfuration >

TAILORED TO YOUR SPECIFIC NEEDS

SIDE FILL

Side Fill reinforces the connection between chips and the board, providing superior protection in environments with high vibration or mechanical stress.

CONFORMAL COATING

Conformal Coating applies a protective acrylic layer over the DRAM PCB, shielding it from harmful elements such as moisture, dust, and corrosive substances.

IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS

TRANSPORTATION
TRANSPORTATION

Our solutions enhance operations, management, and security for EVs, buses, subways, and more.

INDUSTRIAL / EMBEDDED
INDUSTRIAL / EMBEDDED

Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.

SURVEILLANCE & SAFETY
SURVEILLANCE & SAFETY

Our solutions deliver advanced analytics and instant response for modern surveillance needs.

AUTOMATION
AUTOMATION

Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.

SPECIFICATIONS

Model NameDDR4 Wide Temperature SODIMM
DDR GenerationDDR4 Memory
DIMM TypeSODIMM
Speed2133 MT/s, 2400 MT/s, 2666 MT/s, 3200 MT/s
Density4GB, 8GB, 16GB, 32GB
FunctionNon-ECC Unbuffered Memory
Pin Number260pin
Bus Widthx64
Voltage1.2V
PCB Height1.18 Inches
Operating Temperature-40°C ~ 95°C (Tc)
30μ” Gold FingerY
Anti-SulfurationY

ORDER INFORMATION

P/N

IC Config.

Rank

Temp.

Description

M4S0-2GSVZ5EM

256M x 16

1R x 16

-40°C ~ 95°C (Tc)

DDR4 3200 2GB Wide Temperature SODIMM

M4S0-4GSV85EM

256M x 16

2R x 16

-40°C ~ 95°C (Tc)

DDR4 3200 4GB Wide Temperature SODIMM

M4S0-4GSSN5EM

512M x 8

1R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 4GB Wide Temperature SODIMM

M4S0-4GSXZ5EM

512M x 16

1R x 16

-40°C ~ 95°C (Tc)

DDR4 3200 4GB Wide Temperature SODIMM

M4S0-4GMXZ5EM

512M x 16

1R x 16

-40°C ~ 95°C (Tc)

DDR4 3200 4GB Wide Temperature SODIMM

M4S0-8GSX85EM

512M x 16

2R x 16

-40°C ~ 95°C (Tc)

DDR4 3200 8GB Wide Temperature  SODIMM

M4S0-8GSSO5EM

512M x 8

2R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 8GB Wide Temperature  SODIMM

M4S0-8GS1N5EM

1G x 8

1R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 8GB Wide Temperature  SODIMM

M4S0-8GM1N5EM

1G x 8

1R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 8GB Wide Temperature  SODIMM

M4S0-8GSYZ5EM

1G x 16

1R x 16

-40°C ~ 95°C (Tc)

DDR4 3200 8GB Wide Temperature  SODIMM

M4S0-AGSY85EM

1G x 16

2R x 16

-40°C ~ 95°C (Tc)

DDR4 3200 16GB Wide Temperature SODIMM

M4S0-AGS1O5EM

1G x 8

2R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 16GB Wide Temperature SODIMM

M4S0-AGM1O5EM

1G x 8

2R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 16GB Wide Temperature SODIMM

M4S0-AGS2N5EM

2G x 8

1R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 16GB Wide Temperature SODIMM

M4S0-AGM2N5EM

2G x 8

1R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 16GB Wide Temperature SODIMM

M4S0-BGS2O5EM

2G x 8

2R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 32GB Wide Temperature SODIMM

M4S0-BGM2O5EM

2G x 8

2R x 8

-40°C ~ 95°C (Tc)

DDR4 3200 32GB Wide Temperature SODIMM


*Please contact Innodisk for products with other speeds.
