SATADOM
4GB ~ 32GB
SATADOM-SV 3SE3
Features
- SATA III interface
- High IOPS to reduce boot up timing
- Built-in Pin 8 power supply
- Intelligent error recovery system
- Zero mechanical interference
- Anti-vibration mechanical design
- iSMART disk health monitoring
- Supports wide temperature from -40°C to 85°C
Innodisk Serial ATA Disk on Module (SATADOM®) supports SATA III standard (6.0Gb/s) interface with excellent performance, and SATADOM-SV 3SE3 is designed as the smallest form factor size that could enhance compatibility with various design applications.
Innodisk’s patented Pin7 and Pin 8 SATA power supply technologies use the SATA connector itself as a power supply to drive the device without external power cables. It is a 100% cable-less, shock-resistant, space-saving, and plug-and-play storage solution that optimizes airflow and makes the best use of limited board space in embedded and rackmount server systems.
Innodisk SATADOM-SV 3SE3 effectively reduces the boot time of the operation system, and the power consumption is less than that of a hard disk drive (HDD), which complies with ATA protocol. No additional drives are required, and they can be configured as boot devices or data storage devices.
Cable-less Power – SIMPLIFIED CONNECTIVITY
Innodisk’s SATADOM SSDs are designed to integrate seamlessly into embedded systems, industrial computers, or server motherboards. With our patented Pin 7 / Pin 8 Vcc technology, these drives enable plug-and-play functionality, eliminating the need for additional power cables and ensuring a streamlined, cable-free setup.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
SURVEILLANCE & SAFETY
Our solutions deliver advanced analytics and instant response for modern surveillance needs.
SPECIFICATIONS
| Model Name | SATADOM-SV 3SE3 |
|---|---|
| Flash Type | SLC |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | SATADOM-SV |
| Capacity | 4GB ~ 32GB |
| Sequential R / W (MB/sec, max.) | 220 / 110 |
| P/E Cycle | 60,000 |
| TBW (Max.) | 187 |
| Storage Temperature | -55°C ~ 95°C |
| Max. Power Consumption | 0.35W |
| Max. Channels | 2 |
| External DRAM Buffer | N |
| Feature | S.M.A.R.T. |
| Dimension (W x L x H/mm) | 40.4 x 21.03 x 10.4 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 5 Years |
ORDER INFORMATION
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
4GB | DESSV-04GD09SCADB* | DESSV-04GD09SWADB* |
8GB | DESSV-08GD09SCADB* | DESSV-08GD09SWADB* |
16GB | DESSV-16GD09SCADB* | DESSV-16GD09SWADB* |
32GB | DESSV-32GD09SCADB* | DESSV-32GD09SWADB* |
*PN end with A : Pin 8 + power cable / B : Pin 8 + Pin 7
