SATADOM
32GB ~ 256GB
SATADOM-ML 3MG2-P
Features
- Built-in Pin 8 power supply
- SATA 6.0Gb/s interface
- High IOPS to reduce boot up timing
- Innovative firmware algorithm
- Anti-vibration mechanical design
- Built in iData Guard
- Hardware Write Protection supported
- Supports wide temperature from -40°C to 85°C
Innodisk Serial ATA Disk on Module (SATADOM®) supports SATA III standard (6.0Gb/s) interface with excellent performance, and SATADOM®-ML 3MG2-P is designed as the smallest form factor size that could enhance compatibility with various design applications.
The innovative Pin 8 uses the SATA connector itself as a power supply to drive the device without external cables. It could be connected directly to the SATA on-board socket on a customer’s system without an additional power cable. Besides, the boot time and power consumption are lower than those of a hard disk drive (HDD), and it operates reliably in harsh environments while complying with the ATA protocol. No additional drives are required, and the SSD can be configured as a boot device or data storage device.
Cable-less Power – SIMPLIFIED CONNECTIVITY
Innodisk’s SATADOM SSDs are designed to integrate seamlessly into embedded systems, industrial computers, or server motherboards. With our patented Pin 7 / Pin 8 Vcc technology, these drives enable plug-and-play functionality, eliminating the need for additional power cables and ensuring a streamlined, cable-free setup.
Write Protect – SAFEGUARDING DATA SECURITY
With Innodisk SSD’s built-in write protection technology, users can utilize the read-only function to safeguard critical data within flash storage devices, preventing unauthorized modification or malicious use.
iData Guard – DATA PROTECTION TECHNOLOGY
iData Guard enables the immediate sending of a command in the event of a sudden power failure, interrupting read and write commands from the system and ensuring that the last command can be completed. This preserves data integrity on the SSD, protecting data security.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
SURVEILLANCE & SAFETY
Our solutions deliver advanced analytics and instant response for modern surveillance needs.
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
SPECIFICATIONS
| Model Name | SATADOM-ML 3MG2-P |
|---|---|
| Flash Type | MLC |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | SATADOM-ML |
| Capacity | 32GB ~ 256GB |
| Sequential R / W (MB/sec, max.) | 560 / 180 |
| P/E Cycle | 3,000 |
| TBW (Max.) | 250 |
| Storage Temperature | -40°C ~ 85°C |
| Max. Power Consumption | 2.68W |
| Max. Channels | 4 |
| External DRAM Buffer | Y |
| Feature | H/W Write Protect, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 37.17 x 31.5 x 10.2 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 3 Years |
ORDER INFORMATION
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
32GB | DGSML-32GD81BCBDC* | DGSML-32GD81BWBDC* |
64GB | DGSML-64GD81BCBQC* | DGSML-64GD81BWBQC* |
128GB | DGSML-A28D81BCBQC* | DGSML-A28D81BWBQC* |
256GB | DGSML-B56D81BCBQC* | DGSML-B56D81BWBQC* |
*PN end with A : Pin 8 + power cable / B : Pin 8 + Pin 7
