M.2
32GB ~ 2TB
M.2 (S80) 3TE7
Features
- SATA III solution for industrial grade SSD
- Exclusive L³ architecture
- DRAM-less, 100% data integrity
- Excellent random performance
- Supports TRIM / NCQ / S.M.A.R.T.
- Built-in iData Guard
- Designed with hardware LDPC ECC engine
- Supports wide temperature from -40°C to 85°C
Innodisk M.2 (S80) 3TE7 is SATA III 6.0 Gb/s Flash-based disk in industrial-grade field, which adopts latest SATA III NAND controller with Innodisk’s exclusive L³ FW architecture. The upgraded L³ FW architecture, combining Innodisk signature 4K mapping algorithm L² FW architecture with powerful LDPC technology, makes 3TE7 series have outstanding high IOPS, better data integrity and extended lifespan through reducing the bad block number happening. Built-in thermal sensor, and iData Guard ensure data integrity and reliability of 3TE7 for industrial applications.
Innodisk M.2 (S80) 3TE7 is designed for industrial-grade SSD hard drive, and supports several standard features, including TRIM, NCQ, and S.M.A.R.T. In addition, Innodisk’s exclusive industrial-oriented firmware provides a flexible customization service, making it perfect for a variety of industrial applications.
iData Guard – DATA PROTECTION TECHNOLOGY
iData Guard enables the immediate sending of a command in the event of a sudden power failure, interrupting read and write commands from the system and ensuring that the last command can be completed. This preserves data integrity on the SSD, protecting data security.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
ENTERTAINMENT
Our products enhance user experiences in gaming systems and entertainment platforms, ensuring smooth operations and meeting industry standards.
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
COMMUNICATION
Our solutions ensure reliable and uninterrupted performance, supporting networking and critical telecom infrastructure even under heavy loads.
RETAIL
Powering smart retail systems, our solutions enable efficient inventory management, seamless point-of-sale operations, and insightful customer analytics.
SPECIFICATIONS
| Model Name | M.2 (S80) 3TE7 |
|---|---|
| Flash Type | 3D TLC |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | M.2 2280 B+M Key |
| Capacity | 32GB ~ 2TB |
| Sequential R / W (MB/sec, max.) | 560 / 520 |
| P/E Cycle | 3,000 |
| TBW (Max.) | 2,400 |
| Storage Temperature | -40°C ~ 85°C |
| Max. Power Consumption | 2.3W |
| Max. Channels | 4 |
| External DRAM Buffer | N |
| Feature | AES, H/W Write Protect, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 22.0 x 80.0 x 1.35 (Max.) |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 3 Years |
ORDER INFORMATION
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
32GB | DEM28-32GDK1EC1SF | DEM28-32GDK1EW1SF |
64GB | DEM28-64GDK1%C*DF | DEM28-64GDK1%W*DF |
128GB | DEM28-A28DK1%C*QF | DEM28-A28DK1%W*QF |
256GB | DEM28-B56DK1%C*QF | DEM28-B56DK1%W*QF |
512GB | DEM28-C12DK1%C*QF | DEM28-C12DK1%W*QF |
1TB | DEM28-01TDK1%CAQF | DEM28-01TDK1%WAQF |
2TB | DEM28-02TDK1%CAQF | DEM28-02TDK1KWAQF |
%.E : 64 layers 3D TLC / K : 112 layers 3D TLC
*. PCB version control
