M.2
8GB ~ 128GB
M.2 (S80) 3IS4
Features
- SATA III solution for Server Boot-up Drive
- DRAM-less, 100% data integrity
- Excellent random performance
- Designed with hardware LDPC ECC engine
- Cost-effective Flash with iSLC (MLC)
- iData Guard for abnormal power failure
- iSMART disk health monitoring
- Supports wide temperature from -40°C to 85°C
Innodisk M.2 (S80) 3IS4 is characterized by L³ architecture with the latest SATA III (6.0GHz) Marvell NAND controller. Innodisk’s exclusive L³ architecture is L² architecture multiplied LDPC (Low Density Parity Check). L² (Long Life) architecture is a 4K mapping algorithm that reduces WAF and features a real-time wear leveling algorithm to provide high performance and prolong lifespan with exceptional reliability.
Innodisk M.2 (S80) 3IS4 is designed for server field. It effectively reduces the booting time of operation system and has less power consumption compared to hard disk drive (HDD). The great benefit of M.2 (S80) 3IS4 is to be configured as a SATA boot device with no requirement on additional driver and without using a drive bay, making it perfect for server applications.
Write Protect – SAFEGUARDING DATA SECURITY
With Innodisk SSD’s built-in write protection technology, users can utilize the read-only function to safeguard critical data within flash storage devices, preventing unauthorized modification or malicious use.
iData Guard – DATA PROTECTION TECHNOLOGY
iData Guard enables the immediate sending of a command in the event of a sudden power failure, interrupting read and write commands from the system and ensuring that the last command can be completed. This preserves data integrity on the SSD, protecting data security.
Wear Leveling Technology – EXTENDING PRODUCT LIFESPAN
Innodisk adopts innovative wear leveling technology to revolutionize SSD storage methods, thereby improving its lifespan. By applying this technology to both dynamic and static storage blocks, it eliminates the traditional concepts of hot zones and cold zones, achieving full-area wear balance and optimizing the use of every flash memory block.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
DATA CENTER
Driving the backbone of modern computing, our solutions deliver high performance and reliability for data-intensive operations.
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
SPECIFICATIONS
| Model Name | M.2 (S80) 3IS4 |
|---|---|
| Flash Type | iSLC (MLC) |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | M.2 2280 B+M Key |
| Capacity | 8GB ~ 128GB |
| Sequential R / W (MB/sec, max.) | 530 / 380 |
| P/E Cycle | 20,000 |
| TBW (Max.) | 1,388 |
| Storage Temperature | -55°C ~ 95°C |
| Max. Power Consumption | 1.2W |
| Max. Channels | 2 |
| External DRAM Buffer | N |
| Feature | H/W Write Protect, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 22.0 x 80.0 x 3.5 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 5 Years |
ORDER INFORMATION
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
8GB | DSM28-08GM413C1&C | DSM28-08GM413W1&C |
16GB | DSM28-16GM413C1DC | DSM28-16GM413W1DC |
32GB | DSM28-32GM413C1DC | DSM28-32GM413W1DC |
64GB | DSM28-64GM413C1DC | DSM28-64GM413W1DC |
128GB | DSM28-A28M413C1DC | DSM28-A28M413W1DC |
&. S : 1 channel / D : 2 channels
