M.2
32GB ~ 512GB
M.2 (S80) 3IS2-P
Features
- SATA III solution for Server Boot-up Drive
- Cost-effective Flash with iSLC (MLC)
- iSMART disk health monitoring
- Intelligent error recovery system
- High IOPS to enhance boot up timing
- Zero mechanical interference
- iData Guard for abnormal power failure
- Supports wide temperature from -40°C to 85°C
Innodisk M.2 (S80) 3IS2-P is designed as the standard M.2 form factor with SATA interface, and supports SATA III standard (6.0Gb/s) with excellent performance. The form factor refers to the M.2 (NGFF) specification which established by JEDEC.
Innodisk M.2 (S80) 3IS2-P is designed for server field. It effectively reduces the booting time of operation system and has less power consumption compared to hard disk drive (HDD). The great benefit of M.2 (S80) 3IS2-P is to be configured as a SATA boot device with no requirement on additional driver and without using a drive bay, making it perfect for server applications.
iData Guard – DATA PROTECTION TECHNOLOGY
iData Guard enables the immediate sending of a command in the event of a sudden power failure, interrupting read and write commands from the system and ensuring that the last command can be completed. This preserves data integrity on the SSD, protecting data security.
AES 256-bit DATA ENCRYPTION & TCG Opal 2.0 SUPPORT
Innodisk SSDs utilize AES 256-bit encryption, the US government’s standard for securing confidential data, while also supporting TCG Opal 2.0 for enhanced device management and user-friendly authentication.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
DATA CENTER
Driving the backbone of modern computing, our solutions deliver high performance and reliability for data-intensive operations.
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
SPECIFICATIONS
| Model Name | M.2 (S80) 3IS2-P |
|---|---|
| Flash Type | iSLC (MLC) |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | M.2 2280 B+M Key |
| Capacity | 32GB ~ 512GB |
| Sequential R / W (MB/sec, max.) | 560 / 450 |
| P/E Cycle | 20,000 |
| TBW (Max.) | 5,000 |
| Storage Temperature | -55°C ~ 95°C |
| Max. Power Consumption | 1.5W (3.3V x 450mA) |
| Max. Channels | 4 |
| External DRAM Buffer | Y |
| Feature | AES, TCG Opal 2.0, H/W Write Protect, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 22.0 x 80.0 x 3.5 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 5 Years |
ORDER INFORMATION
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
32GB | DSM28-32GD813CAQC | DSM28-32GD813WAQC |
64GB | DSM28-64GD813CAQC | DSM28-64GD813WAQC |
128GB | DSM28-A28D813CAQC | DSM28-A28D813WAQC |
256GB | DSM28-B56D813CAQC | DSM28-B56D813WAQC |
512GB | DSM28-C12D813CAQC | DSM28-C12D813WAQC |
