M.2
32GB ~ 512GB
M.2 (S60) 3ME3
Features
- SATA 6.0Gb/s interface
- iSMART disk health monitoring
- Intelligent error recovery system
- Excellent data transfer speed
- Zero mechanical interference
- Anti-vibration mechanical design
- Supports wide temperature from -40°C to 85°C
Innodisk M.2 (S60) 3ME3 is designed as the standard M.2 form factor with SATA interface, and supports SATA III standard (6.0Gb/s) with excellent performance. The form factor refers to the M.2 (NGFF) specification which established by JEDEC. Regarding of mechanical interference, Innodisk M.2 (S60) 3ME3 absolutely replaces the traditional hard disk and makes personal computer, in any field, smaller and easier.
Innodisk M.2 (S60) 3ME3 effectively reduces the booting time of operation system, and the power consumption is less than hard disk drive (HDD), and complies with ATA protocol, no additional drivers are required, and can be configured as a boot device or data storage device.
Write Protect – SAFEGUARDING DATA SECURITY
With Innodisk SSD’s built-in write protection technology, users can utilize the read-only function to safeguard critical data within flash storage devices, preventing unauthorized modification or malicious use.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
SPECIFICATIONS
| Model Name | M.2 (S60) 3ME3 |
|---|---|
| Flash Type | MLC |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | M.2 2260 B+M Key |
| Capacity | 32GB ~ 512GB |
| Sequential R / W (MB/sec, max.) | 380 / 200 |
| P/E Cycle | 3,000 |
| TBW (Max.) | 150 |
| Storage Temperature | -55°C ~ 95°C |
| Max. Power Consumption | 1.3W |
| Max. Channels | 4 |
| External DRAM Buffer | N |
| Feature | H/W Write Protect, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 22.0 x 60.0 x 3.5 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 2 Years |
ORDER INFORMATION
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
32GB | DEM26-32GD08BCADC | DEM26-32GD08BWADC |
64GB | DEM26-64GD08BCAQC | DEM26-64GD08BWAQC |
128GB | DEM26-A28D08BCAQC | DEM26-A28D08BWAQC |
256GB | DEM26-B56D08BCAQC | DEM26-B56D08BWAQC |
512GB | DEM26-C12D08BCAQC | DEM26-C12D08BWAQC |
