CFast
8GB ~ 128GB
CFast 3IE3
Features
- Innovative firmware algorithm
- DRAM-less, 100% data integrity
- Excellent random performance
- Supports TRIM / NCQ / SMART
- Built in iData Guard
- Supports wide temperature from -40°C to 85°C
The Innodisk CFast 3IE3 operates at SATA III 6.0 Gb/s, which offers data transfer rate of read up to 240MB/s, and of sequential write up to 160MB/s. Compliant with CFast 2.0 standard, it is designed with 7+17 pin connector and is SATA compatible. Due to the idle power saving, it reduces 30% power consumption. CFast 3IE3 is featured as small form factor, and suitable for most industrial application.
CFast 3IE3 can work under harsh environment, and complies with ATA protocol. Without additional drives, the disk can be configured as a boot device or data storage device. CFast 3IE3 support hardware write protect to prevent modification of valuable data on a device. Besides, through Innodisk's enhanced power cycling technology and more capacitors, CFast 3IE3 prevents data loss caused by sudden power failure. By using Innodisk's iSMART, users can not only monitor the operation status of CFast, but also visualize Wear-Leveling status with graphics.
iData Guard – DATA PROTECTION TECHNOLOGY
iData Guard enables the immediate sending of a command in the event of a sudden power failure, interrupting read and write commands from the system and ensuring that the last command can be completed. This preserves data integrity on the SSD, protecting data security.
Garbage Collection and TRIM Technologies – OPTIMIZING SSD PERFORMANCE
Garbage Collection is a process where data that is still in use is copied to a new block, and the old block is then cleared of all data. With TRIM technology, the number of operations required for Garbage Collection is minimized, reducing unnecessary wear on the SSD and enhancing its longevity.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
SPECIFICATIONS
| Model Name | CFast 3IE3 |
|---|---|
| Flash Type | iSLC (MLC) |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | CFast 2.0 |
| Capacity | 8GB ~ 128GB |
| Sequential R / W (MB/sec, max.) | 240 / 160 |
| P/E Cycle | 20,000 |
| TBW (Max.) | 347 |
| Storage Temperature | -55°C ~ 95°C |
| Max. Power Consumption | 1.1W |
| Max. Channels | 2 |
| External DRAM Buffer | N |
| Feature | H/W Write Protect, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 42.8 x 36.4 x 3.6 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 5 Years |
ORDER INFORMATION
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
8GB | DHCFA-08GD09BC1SC(W) | DHCFA-08GD09BW1SC(W) |
16GB | DHCFA-16GD09BC1DC(W) | DHCFA-16GD09BW1DC(W) |
32GB | DHCFA-32GD09BC1DC(W) | DHCFA-32GD09BW1DC(W) |
64GB | DHCFA-64GD09BC1DC(W) | DHCFA-64GD09BW1DC(W) |
128GB | DHCFA-A28D09BC1DC(W) | DHCFA-A28D09BW1DC(W) |
(W) : H/W write protect function (Optional)
