SD Card & MicroSD Card
128MB ~ 32GB
Industrial SLC SD Card
Features
- Support static and global wear leveling
- S.M.A.R.T. monitoring compatibility
- Intelligent error recovery system
- High-speed data transfer capabilities
- Enhanced power cycling for improved reliability
- 30μ” gold-plated contacts (gold finger)
The Innodisk Industrial SD card is a slim, SLC-based storage solution designed for portable devices. A built-in ECC function can help detect and correct errors during data transfer. It is also compatible with SD 1.1 and SD 2.0 standards and supports SDHC Class 10 and SPI modes. Innodisk’s Industrial SD card consumes little power and has capacities ranging from 128MB to 32GB.
Write Protect – SAFEGUARDING DATA SECURITY
With Innodisk SSD’s built-in write protection technology, users can utilize the read-only function to safeguard critical data within flash storage devices, preventing unauthorized modification or malicious use.
Wear Leveling Technology – EXTENDING PRODUCT LIFESPAN
Innodisk adopts innovative wear leveling technology to revolutionize SSD storage methods, thereby improving its lifespan. By applying this technology to both dynamic and static storage blocks, it eliminates the traditional concepts of hot zones and cold zones, achieving full-area wear balance and optimizing the use of every flash memory block.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
SPECIFICATIONS
| Model Name | Industrial SLC SD Card |
|---|---|
| Interface | SD 1.01 / 2.00 |
| Flash Type | SLC |
| Form Factor | SD Card |
| Capacity | 128MB ~ 32GB |
| Sequential R / W (MB/sec, max.) | 20 / 16 |
| P/E Cycle | 60,000 |
| TBW (Max.) | -- |
| Storage Temperature | -55°C ~ 95°C |
| Max. Power Consumption | 0.2W |
| Max. Channels | 1 |
| External DRAM Buffer | N |
| Features | H/W Write Protect, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 24.0 x 32.0 x 2.1 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 5 Years |
ORDER INFORMATION
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
128MB (24nm) | DS2A-128I81C1B | DS2A-128I81W1B |
256MB (24nm) | DS2A-256I81C1B | DS2A-256I81W1B |
512MB (32nm) | DS2A-512I81C1B | DS2A-512I81W1B |
512MB (24nm) | DESDC-512I81AC1SB | DESDC-512I81AW1SB |
1GB (32nm) | DS2A-01GI81C1B | DS2A-01GI81W1B |
1GB (24nm) | DESDC-01GI81AC1SB | DESDC-01GI81AW1SB |
2GB (32nm) | DS2A-02GI81C1B | DS2A-02GI81W1B |
2GB (24nm) | DESDC-02GI81AC1SB | DESDC-02GI81AW1SB |
4GB (24nm) | DS2A-04GI81C1B | DS2A-04GI81W1B |
8GB (24nm) | DS2A-08GI81C1B | DS2A-08GI81W1B |
16GB (24nm) | DS2A-16GI81C1B | DS2A-16GI81W1B |
32GB (24nm) | DS2A-32GI81C1B | DS2A-32GI81W1B |
