Product Features
  • Supports dual GbE LAN ports
  • Two independent PSE channels
  • Supports 12V~24V power input via 4pin header
  • Complies with IEEE 802.3af, up to 15.4W at 48V per PoE port.
  • Complies with EN61000-4-2 (ESD) Air-15kV, Contact- 8kV
  • Industrial temperature -40 ºC to 85 ºC
Featured Technologies:
Specs Order Information Related Resource +ADD TO INQUIRY


Module NameEMPL-G2P1
Module TypemPCIe to dual PoE Module
Form FactormPCIe
Input I/FPCI Express 2.1 x 1
Output I/FPoE x 2
Output connectorRJ45 x 2
Power Consumption30W
Dimensions (W x L x H/mm)Main Board: 30 x 50.9 x 9.2
Daughter Board: 58.2 x 72.7 x 23.8
TemperatureOperation: STD temp: 0°~70°C; W/T temp: -40°C ~ +85°C
Storage: -55°C ~ +95°C
EnvironmentVibration: 5G @7~2000Hz
Shock: 50G @ 0.5ms
NotesPlease download driver from Intel official website.
Windows: XP(32bit), 7(32/64bit), 8/8.1(32/64 bit), 10(32/64bit)
Linux: kernel 2.4 series, 2.6.x and 3.x version.

Order Information:

P/N Description P/N Description
EMPL-G2P1-C1 Mounting hole, 4pin header, Standard Temp. EMPL-G2P1-C3 Mounting hole, DC Jack, Standard Temp.
EMPL-G2P1-W1 Mounting hole, 4pin header, Wide Temp. EMPL-G2P1-W3 Mounting hole, DC Jack, Wide Temp.
EMPL-G2P1-C2 Bracket, 4pin header, Standard Temp. EMPL-G2P1-C4 Bracket, DC Jack, Standard Temp.
EMPL-G2P1-W2 Bracket, 4pin header, Wide Temp. EMPL-G2P1-W4 Bracket, DC Jack, Wide Temp.
