DDR
Non-ECC Unbuffered Memory
DDR SODIMM
Features
- Small Outline Dual In-line Memory Module
- Fully Tested and Optimized for Stability and Performance
- Uses Original IC to Meet Strict Industrial Standards
- JEDEC Standard 2.6V +/- 0.2V
- Operating Environment : 0°C ~ 70°C
- RoHS Compliance
DDR SODIMM is a compact memory module that provides lasting performance and is designed for the embedded, surveillance and automation markets. The modules include single bit error correction, are available in 256MB, 512MB, and 1GB capacities, and with data transfer rates of 333MT/s and 400MT/s.
TAILORED TO YOUR SPECIFIC NEEDS
SIDE FILL
Side Fill reinforces the connection between chips and the board, providing superior protection in environments with high vibration or mechanical stress.
CONFORMAL COATING
Conformal Coating applies a protective acrylic layer over the DRAM PCB, shielding it from harmful elements such as moisture, dust, and corrosive substances.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
SURVEILLANCE & SAFETY
Our solutions deliver advanced analytics and instant response for modern surveillance needs.
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
SPECIFICATIONS
| Model Name | DDR SODIMM |
|---|---|
| DDR Generation | DDR Memory |
| DIMM Type | SODIMM |
| Speed | 333 MT/s, 400 MT/s |
| Density | 256MB, 512MB, 1GB |
| Function | Non-ECC Unbuffered Memory |
| Pin Number | 200pin |
| Bus Width | x64 |
| Voltage | 2.6V |
| PCB Height | 1.25 Inches |
| Operating Temperature | 0°C ~ 70°C |
ORDER INFORMATION
P/N | IC Config. | Rank | Temp. | Description |
M1SF-56MB3C03-J | 32M x 16 | 1R x 16 | 0°C ~ 70°C | DDR 400 256MB SODIMM |
M1SF-12MB3C03-J | 32M x 8 | 2R x 16 | 0°C ~ 70°C | DDR 400 512MB SODIMM |
M1SF-12MCSC03-J | 64M x 8 | 1R x 8 | 0°C ~ 70°C | DDR 400 512MB SODIMM |
M1SF-1GMCVC03-J | 64M x 8 / BGA | 2R x 8 | 0°C ~ 70°C | DDR 400 1GB SODIMM |
*Please contact Innodisk for products with other speeds.
