Embedded Disk Card
8GB ~ 32GB
EDC 1SE2 Vertical
Features
- iSMART disk health monitoring
- Intelligent error recovery system
- Excellent data transfer speed
- Write Protection security
- Enhanced power cycling management
The Innodisk Embedded Disk Card 1SE2 (EDC 1SE2) products provide high-capacity solid-state Flash memory that electrically complies with the Personal Computer Memory Card International Association ATA standard. Innodisk Embedded Disk Card 1SE2 (EDC 1SE2) is an embedded solid-state data storage system for industrial workplaces. Embedded Disk Card 1SE2 (EDC 1SE2) features an extremely lightweight, reliable, low-profile form factor.
Embedded Disk Card 1SE2 (EDC 1SE2) supports advanced PIO (0-6), Multi-word DMA (0-4), Ultra DMA (0-6) transfer modes, multi-sector transfers, and LBA addressing.
Write Protect – SAFEGUARDING DATA SECURITY
With Innodisk SSD’s built-in write protection technology, users can utilize the read-only function to safeguard critical data within flash storage devices, preventing unauthorized modification or malicious use.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
SPECIFICATIONS
| Model Name | EDC 1SE2 Vertical |
|---|---|
| Flash Type | SLC |
| Interface | PATA |
| Form Factor | Embedded Disk Card |
| Capacity | 8GB ~ 32GB |
| Sequential R / W (MB/sec, max.) | 110 / 75 |
| P/E Cycle | 60,000 |
| TBW (Max.) | -- |
| Storage Temperature | -55°C ~ 95°C |
| Max. Power Consumption | 0.76V |
| Max. Channels | 2 |
| External DRAM Buffer | N |
| Features | H/W Write Protect, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 50.3 x 27.3 x 5.8 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 5 Years |
ORDER INFORMATION
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
8GB | DEE4H-08GD53AC1DB | DEE4H-08GD53AW1DB |
16GB | DEE4H-16GD53AC1DB | DEE4H-16GD53AW1DB |
32GB | DEE4H-32GD53AC1DB | DEE4H-32GD53AW1DB |
